Firebase Data Connect: GraphQL + Cloud SQL

1Mobile/Web App
2    ↓ (Type-safe SDK)
3Firebase Data Connect Service
4    ↓ (GraphQL)
5Cloud SQL for PostgreSQL

1# Update Firebase CLI
2npm install -g firebase-tools@latest
3
4# Initialize Data Connect
5firebase init dataconnect
6
7# Project structure is created:
8# dataconnect/
9#   ├-- schema/        → GraphQL schema files
10#   ├-- connector/     → Query and mutation definitions
11#   └-- dataconnect.yaml

1# dataconnect/schema/schema.gql — minimal blog schema
2type Post @table {
3  id: UUID! @default(expr: "uuidV4()")
4  title: String!
5  slug: String! @unique
6  content: String!
7  status: PostStatus! @default(value: "DRAFT")
8  author: User! @relation
9  publishedAt: Timestamp
10  createdAt: Timestamp! @default(expr: "request.time")
11}
12
13enum PostStatus { DRAFT PUBLISHED ARCHIVED }
14
15# connector/queries.gql — list published posts
16query ListPosts($limit: Int! = 10) @auth(level: PUBLIC) {
17  posts(
18    where: { status: { eq: PUBLISHED } }
19    orderBy: [{ publishedAt: DESC }]
20    limit: $limit
21  ) {
22    id title slug publishedAt
23    author { displayName }
24  }
25}

1# dataconnect/schema/schema.gql
2
3# User table
4type User @table {
5  id: UUID! @default(expr: "uuidV4()")
6  email: String! @unique
7  displayName: String!
8  photoUrl: String
9  bio: String
10  createdAt: Timestamp! @default(expr: "request.time")
11  updatedAt: Timestamp! @default(expr: "request.time")
12}
13
14# Blog post
15type Post @table {
16  id: UUID! @default(expr: "uuidV4()")
17  title: String!
18  slug: String! @unique
19  content: String!
20  excerpt: String
21  status: PostStatus! @default(value: "DRAFT")
22  publishedAt: Timestamp
23  author: User! @relation
24  category: Category @relation
25  viewCount: Int! @default(value: 0)
26  createdAt: Timestamp! @default(expr: "request.time")
27}
28
29# Category
30type Category @table {
31  id: UUID! @default(expr: "uuidV4()")
32  name: String! @unique
33  slug: String! @unique
34  description: String
35  posts: [Post!]! @relation  # Reverse relation
36}
37
38# Comment
39type Comment @table {
40  id: UUID! @default(expr: "uuidV4()")
41  content: String!
42  author: User! @relation
43  post: Post! @relation
44  parentComment: Comment @relation  # Nested comments
45  createdAt: Timestamp! @default(expr: "request.time")
46}
47
48# Like (many-to-many)
49type Like @table(
50  key: ["user", "post"]  # Composite primary key
51) {
52  user: User! @relation
53  post: Post! @relation
54  createdAt: Timestamp! @default(expr: "request.time")
55}
56
57# Enum
58enum PostStatus {
59  DRAFT
60  PUBLISHED
61  ARCHIVED
62}

1# dataconnect/connector/queries.gql
2
3# Get all published posts (with pagination)
4query ListPublishedPosts(
5  $limit: Int! = 10,
6  $offset: Int! = 0,
7  $categorySlug: String
8) @auth(level: PUBLIC) {
9  posts(
10    where: {
11      status: { eq: PUBLISHED },
12      category: { slug: { eq: $categorySlug } }
13    },
14    orderBy: [{ publishedAt: DESC }],
15    limit: $limit,
16    offset: $offset
17  ) {
18    id
19    title
20    slug
21    excerpt
22    publishedAt
23    viewCount
24    author {
25      displayName
26      photoUrl
27    }
28    category {
29      name
30      slug
31    }
32  }
33}
34
35# Single post detail (by slug)
36query GetPostBySlug($slug: String!) @auth(level: PUBLIC) {
37  post: posts_findMany(where: { slug: { eq: $slug }, status: { eq: PUBLISHED } }) {
38    id
39    title
40    slug
41    content
42    publishedAt
43    viewCount
44    author {
45      id
46      displayName
47      photoUrl
48      bio
49    }
50    category {
51      name
52      slug
53    }
54    comments(orderBy: [{ createdAt: DESC }]) {
55      id
56      content
57      createdAt
58      author {
59        displayName
60        photoUrl
61      }
62    }
63  }
64}
65
66# User profile and stats
67query GetUserProfile($userId: UUID!) @auth(level: USER) {
68  user(id: $userId) {
69    id
70    displayName
71    email
72    bio
73    photoUrl
74    posts_on_author(where: { status: { eq: PUBLISHED } }) {
75      id
76      title
77      viewCount
78    }
79    comments_on_author {
80      id
81    }
82    likes_on_user {
83      post {
84        id
85        title
86      }
87    }
88  }
89}

1# dataconnect/connector/mutations.gql
2
3# Create a new post
4mutation CreatePost($data: Post_Data!) @auth(level: USER) {
5  post_insert(data: $data)
6}
7
8# Update post (author only)
9mutation UpdatePost(
10  $postId: UUID!,
11  $title: String,
12  $content: String,
13  $status: PostStatus
14) @auth(expr: "auth.uid == this.author.id") {
15  post_update(
16    id: $postId,
17    data: {
18      title: $title,
19      content: $content,
20      status: $status,
21      updatedAt_expr: "request.time"
22    }
23  )
24}
25
26# Add a comment
27mutation AddComment(
28  $postId: UUID!,
29  $content: String!,
30  $parentCommentId: UUID
31) @auth(level: USER) {
32  comment_insert(data: {
33    content: $content,
34    post: { id: $postId },
35    author: { id_expr: "auth.uid" },
36    parentComment: { id: $parentCommentId }
37  })
38}
39
40# Toggle like
41mutation ToggleLike($postId: UUID!) @auth(level: USER) {
42  like_upsert(data: {
43    user: { id_expr: "auth.uid" },
44    post: { id: $postId }
45  })
46}
47
48# Delete post (soft delete → ARCHIVED)
49mutation ArchivePost($postId: UUID!) @auth(expr: "auth.uid == this.author.id") {
50  post_update(
51    id: $postId,
52    data: { status: ARCHIVED }
53  )
54}

1# Generate SDKs
2firebase dataconnect:sdk:generate
3
4# Output:
5# ├-- ios/             → Swift SDK
6# ├-- android/         → Kotlin SDK
7# ├-- dart/            → Flutter SDK
8# └-- web/             → TypeScript SDK

1// Auto-generated — DO NOT edit by hand
2import {
3  listPublishedPosts,
4  getPostBySlug,
5  createPost,
6  toggleLike,
7  ListPublishedPostsData,
8} from '@firebasegen/my-connector';
9
10// Type-safe query
11const posts: ListPublishedPostsData = await listPublishedPosts({
12  limit: 10,
13  offset: 0,
14  categorySlug: 'typescript',
15});
16
17// posts.posts[0].title → string (type-safe!)
18// posts.posts[0].author.displayName → string
19
20// Type-safe mutation
21await createPost({
22  data: {
23    title: 'New Post',
24    slug: 'new-post',
25    content: 'Content...',
26    status: 'DRAFT',
27    // author automatic: auth.uid
28  },
29});

1import FirebaseDataConnect
2
3// Auto-generated connector
4let connector = DataConnect.dataConnect(
5  connectorConfig: ConnectorConfig(
6    serviceId: "my-service",
7    location: "us-central1"
8  )
9)
10
11// Type-safe query
12func loadPosts(category: String? = nil) async throws -> [Post] {
13    let result = try await ListPublishedPostsQuery
14        .ref(limit: 10, offset: 0, categorySlug: category)
15        .execute()
16
17    return result.data.posts.map { post in
18        Post(
19            id: post.id,
20            title: post.title,
21            slug: post.slug,
22            excerpt: post.excerpt ?? "",
23            authorName: post.author.displayName,
24            categoryName: post.category?.name ?? "General"
25        )
26    }
27}
28
29// Type-safe mutation
30func createNewPost(title: String, content: String) async throws {
31    try await CreatePostMutation
32        .ref(data: Post_Data(
33            title: title,
34            slug: title.slugified(),
35            content: content,
36            status: .draft
37        ))
38        .execute()
39}
40
41// Toggle like
42func toggleLike(postId: UUID) async throws {
43    try await ToggleLikeMutation
44        .ref(postId: postId)
45        .execute()
46}

1import 'package:firebase_data_connect/firebase_data_connect.dart';
2import 'package:my_connector/my_connector.dart';
3
4class PostRepository {
5  final _connector = MyConnector.instance;
6
7  // Get published posts
8  Future<List<Post>> getPublishedPosts({
9    int limit = 10,
10    int offset = 0,
11    String? categorySlug,
12  }) async {
13    final result = await _connector.listPublishedPosts
14        .ref(
15          limit: limit,
16          offset: offset,
17          categorySlug: categorySlug,
18        )
19        .execute();
20
21    return result.data.posts.map((p) => Post(
22      id: p.id,
23      title: p.title,
24      slug: p.slug,
25      excerpt: p.excerpt ?? '',
26      authorName: p.author.displayName,
27      viewCount: p.viewCount,
28    )).toList();
29  }
30
31  // Single post by slug
32  Future<PostDetail?> getPostBySlug(String slug) async {
33    final result = await _connector.getPostBySlug
34        .ref(slug: slug)
35        .execute();
36
37    final posts = result.data.post;
38    if (posts.isEmpty) return null;
39
40    final p = posts.first;
41    return PostDetail(
42      id: p.id,
43      title: p.title,
44      content: p.content,
45      author: Author(
46        name: p.author.displayName,
47        photo: p.author.photoUrl,
48      ),
49      comments: p.comments.map((c) => Comment(
50        content: c.content,
51        authorName: c.author.displayName,
52        createdAt: c.createdAt,
53      )).toList(),
54    );
55  }
56}

1# Only the resource owner can edit
2mutation UpdateProfile($data: User_Data!)
3  @auth(expr: "auth.uid == vars.data.id") {
4  user_update(data: $data)
5}
6
7# Admin role check
8mutation DeletePost($postId: UUID!)
9  @auth(expr: "'admin' in auth.token.roles") {
10  post_delete(id: $postId)
11}
12
13# Time-based check (last 24 hours)
14mutation EditComment($commentId: UUID!, $content: String!)
15  @auth(expr: "auth.uid == this.author.id && (request.time - this.createdAt) < duration('24h')") {
16  comment_update(id: $commentId, data: { content: $content })
17}

1# After making a schema change
2firebase dataconnect:sql:migrate --force
3
4# To see the migration SQL
5firebase dataconnect:sql:diff

1# BAD: fetch all fields (over-fetching)
2query GetPosts @auth(level: PUBLIC) {
3  posts {
4    id title slug content excerpt status
5    publishedAt viewCount createdAt updatedAt
6    author { id displayName email photoUrl bio }
7    comments { id content author { id displayName } }
8  }
9}
10
11# GOOD: only the fields you need
12query GetPostCards @auth(level: PUBLIC) {
13  posts(
14    where: { status: { eq: PUBLISHED } }
15    limit: 10
16  ) {
17    id title slug excerpt
18    author { displayName }
19    category { name }
20  }
21}

1# Define an index in the schema
2type Post @table @index(fields: ["status", "publishedAt"]) {
3  # ...
4}
5
6# Composite index
7type Comment @table @index(fields: ["post", "createdAt"]) {
8  # ...
9}
