visionOS 2: Spatial Computing ile Production App Geliştirme 2026

1import SwiftUI
2import RealityKit
3
4@main
5struct SpatialApp: App {
6    var body: some Scene {
7        // Standard 2D pencere
8        WindowGroup {
9            ContentView()
10        }
11
12        // 3D volumetric pencere
13        WindowGroup(id: "3D-Model-Viewer") {
14            ModelViewerView()
15        }
16        .windowStyle(.volumetric)
17        .defaultSize(width: 0.8, height: 0.8, depth: 0.4, in: .meters)
18
19        // Immersive deneyim
20        ImmersiveSpace(id: "Main-Immersive") {
21            ImmersiveView()
22        }
23        .immersionStyle(
24            selection: .constant(.mixed),
25            in: .mixed, .progressive, .full
26        )
27    }
28}
29
30// Immersive space'e geçiş
31struct ContentView: View {
32    @Environment(\.openImmersiveSpace) private var openImmersiveSpace
33    @Environment(\.dismissImmersiveSpace) private var dismissImmersiveSpace
34    @Environment(\.openWindow) private var openWindow
35
36    @State private var immersiveSpaceIsShown = false
37
38    var body: some View {
39        NavigationStack {
40            VStack(spacing: 20) {
41                Button("3D Model Görüntüle") {
42                    openWindow(id: "3D-Model-Viewer")
43                }
44                .buttonStyle(.bordered)
45
46                Button(immersiveSpaceIsShown ? "Çık" : "Immersive Moda Geç") {
47                    Task {
48                        if immersiveSpaceIsShown {
49                            await dismissImmersiveSpace()
50                            immersiveSpaceIsShown = false
51                        } else {
52                            let result = await openImmersiveSpace(id: "Main-Immersive")
53                            immersiveSpaceIsShown = result == .opened
54                        }
55                    }
56                }
57                .buttonStyle(.borderedProminent)
58            }
59            .navigationTitle("Spatial App")
60            .padding()
61        }
62    }
63}

1import ARKit
2import RealityKit
3import SwiftUI
4
5class EnvironmentTracker: ObservableObject {
6    private let arSession = ARKitSession()
7    private let planeDetection = PlaneDetectionProvider(
8        alignments: [.horizontal, .vertical]
9    )
10    private let sceneReconstruction = SceneReconstructionProvider(
11        modes: [.classification]
12    )
13
14    @Published var detectedPlanes: [PlaneAnchor] = []
15    @Published var meshAnchors: [MeshAnchor] = []
16
17    func startTracking() async {
18        guard PlaneDetectionProvider.isSupported,
19              SceneReconstructionProvider.isSupported else {
20            print("Environment API not supported")
21            return
22        }
23
24        do {
25            try await arSession.run([planeDetection, sceneReconstruction])
26        } catch {
27            print("ARKit session error: \(error)")
28            return
29        }
30
31        // Plane detection updates
32        for await update in planeDetection.anchorUpdates {
33            await handlePlaneUpdate(update)
34        }
35    }
36
37    @MainActor
38    private func handlePlaneUpdate(_ update: AnchorUpdate<PlaneAnchor>) {
39        switch update.event {
40        case .added:
41            detectedPlanes.append(update.anchor)
42        case .updated:
43            if let index = detectedPlanes.firstIndex(
44                where: { $0.id == update.anchor.id }
45            ) {
46                detectedPlanes[index] = update.anchor
47            }
48        case .removed:
49            detectedPlanes.removeAll { $0.id == update.anchor.id }
50        }
51    }
52}
53
54// Persistent anchor: Nesneleri gerçek dünyaya sabitleme
55class PersistentAnchorManager {
56    private let worldTracking = WorldTrackingProvider()
57    private let arSession = ARKitSession()
58
59    // visionOS 2: Persistent anchor kaydetme
60    func saveAnchor(
61        entity: Entity,
62        in realityView: RealityView<some View>
63    ) async throws -> UUID {
64        // WorldAnchor oluştur
65        var anchor = WorldAnchor(
66            originFromAnchorTransform: entity.transformMatrix(
67                relativeTo: nil
68            )
69        )
70
71        // Anchor"ı kaydet
72        try await worldTracking.queryDeviceAnchor(atTimestamp: CACurrentMediaTime())
73
74        return anchor.id
75    }
76
77    // Kaydedilmiş anchor"ı geri yükle
78    func loadSavedAnchor(id: UUID) async -> WorldAnchor? {
79        for await update in worldTracking.anchorUpdates {
80            if update.anchor.id == id {
81                return update.anchor
82            }
83        }
84        return nil
85    }
86}

1import ARKit
2import simd
3
4class HandTracker: ObservableObject {
5    private let handTracking = HandTrackingProvider()
6    private let arSession = ARKitSession()
7
8    @Published var leftHand: HandSkeleton?
9    @Published var rightHand: HandSkeleton?
10    @Published var detectedGesture: CustomGesture = .none
11
12    enum CustomGesture {
13        case none
14        case pinch
15        case openPalm
16        case pointingUp
17        case fist
18        case thumbsUp
19    }
20
21    func startTracking() async {
22        guard HandTrackingProvider.isSupported else {
23            print("Hand tracking not supported")
24            return
25        }
26
27        do {
28            try await arSession.run([handTracking])
29        } catch {
30            print("Hand tracking error: \(error)")
31            return
32        }
33
34        for await update in handTracking.anchorUpdates {
35            await handleHandUpdate(update)
36        }
37    }
38
39    @MainActor
40    private func handleHandUpdate(_ update: AnchorUpdate<HandAnchor>) {
41        let hand = update.anchor
42
43        switch hand.chirality {
44        case .left:
45            leftHand = hand.handSkeleton
46        case .right:
47            rightHand = hand.handSkeleton
48            if let skeleton = hand.handSkeleton {
49                detectedGesture = detectGesture(skeleton: skeleton)
50            }
51        }
52    }
53
54    // 27-joint data ile custom gesture detection
55    private func detectGesture(skeleton: HandSkeleton) -> CustomGesture {
56        // Parmak joint'lerini al
57        let thumbTip = skeleton.joint(.thumbTip)
58        let indexTip = skeleton.joint(.indexFingerTip)
59        let middleTip = skeleton.joint(.middleFingerTip)
60        let ringTip = skeleton.joint(.ringFingerTip)
61        let littleTip = skeleton.joint(.littleFingerTip)
62
63        let thumbKnuckle = skeleton.joint(.thumbKnuckle)
64        let indexKnuckle = skeleton.joint(.indexFingerKnuckle)
65
66        guard thumbTip.isTracked, indexTip.isTracked else {
67            return .none
68        }
69
70        // Pinch detection: thumb ve index arası mesafe
71        let thumbPos = simd_float3(thumbTip.anchorFromJointTransform.columns.3.x,
72                                   thumbTip.anchorFromJointTransform.columns.3.y,
73                                   thumbTip.anchorFromJointTransform.columns.3.z)
74        let indexPos = simd_float3(indexTip.anchorFromJointTransform.columns.3.x,
75                                   indexTip.anchorFromJointTransform.columns.3.y,
76                                   indexTip.anchorFromJointTransform.columns.3.z)
77
78        let pinchDistance = simd_distance(thumbPos, indexPos)
79
80        if pinchDistance < 0.02 { // 2cm
81            return .pinch
82        }
83
84        // Thumbs up detection
85        let thumbTipPos = simd_float3(
86            thumbTip.anchorFromJointTransform.columns.3.x,
87            thumbTip.anchorFromJointTransform.columns.3.y,
88            thumbTip.anchorFromJointTransform.columns.3.z
89        )
90        let thumbKnucklePos = simd_float3(
91            thumbKnuckle.anchorFromJointTransform.columns.3.x,
92            thumbKnuckle.anchorFromJointTransform.columns.3.y,
93            thumbKnuckle.anchorFromJointTransform.columns.3.z
94        )
95
96        let thumbDirection = simd_normalize(thumbTipPos - thumbKnucklePos)
97        if thumbDirection.y > 0.8 && pinchDistance > 0.05 {
98            return .thumbsUp
99        }
100
101        // Open palm: tüm parmaklar uzanmış
102        let allExtended = [indexTip, middleTip, ringTip, littleTip].allSatisfy {
103            $0.isTracked
104        }
105
106        if allExtended && pinchDistance > 0.06 {
107            return .openPalm
108        }
109
110        return .none
111    }
112}
113
114// Custom gesture ile RealityKit etkileşimi
115struct HandTrackingRealityView: View {
116    @StateObject private var handTracker = HandTracker()
117    @State private var selectedEntity: Entity?
118
119    var body: some View {
120        RealityView { content in
121            // 3D model yükle
122            if let model = try? await Entity(
123                named: "robot",
124                in: .main
125            ) {
126                model.name = "robot"
127                model.position = [0, 0, -0.5]
128                content.add(model)
129            }
130        }
131        .task {
132            await handTracker.startTracking()
133        }
134        .onChange(of: handTracker.detectedGesture) { _, gesture in
135            handleGesture(gesture)
136        }
137    }
138
139    private func handleGesture(_ gesture: HandTracker.CustomGesture) {
140        switch gesture {
141        case .pinch:
142            // Nesneleri pinch ile tutma
143            print("Pinch detected — grab object")
144        case .thumbsUp:
145            // Onay aksiyonu
146            print("Thumbs up — confirm")
147        case .openPalm:
148            // Menu aç
149            print("Open palm — show menu")
150        default:
151            break
152        }
153    }
154}

1import RealityKit
2import SwiftUI
3
4// RealityKit entity"inde hover ve gaze interaction
5struct GazeInteractiveView: View {
6    var body: some View {
7        RealityView { content in
8            // Interaktif küre oluştur
9            let sphere = ModelEntity(
10                mesh: .generateSphere(radius: 0.1),
11                materials: [SimpleMaterial(
12                    color: .systemBlue,
13                    isMetallic: false
14                )]
15            )
16
17            // visionOS 2: Input target ve collision ekle
18            sphere.components.set(InputTargetComponent())
19            sphere.components.set(CollisionComponent(
20                shapes: [.generateSphere(radius: 0.1)]
21            ))
22
23            // Hover effect — gaze ile etkileşim
24            sphere.components.set(HoverEffectComponent(
25                .highlight(.init(
26                    color: .white,
27                    strength: 3.0
28                ))
29            ))
30
31            sphere.position = [0, 1.5, -0.5]
32            content.add(sphere)
33        }
34        .gesture(
35            SpatialTapGesture()
36                .targetedToAnyEntity()
37                .onEnded { value in
38                    handleTap(on: value.entity)
39                }
40        )
41    }
42
43    private func handleTap(on entity: Entity) {
44        // Tap animasyonu
45        var transform = entity.transform
46        transform.scale = SIMD3<Float>(1.2, 1.2, 1.2)
47
48        entity.move(
49            to: transform,
50            relativeTo: entity.parent,
51            duration: 0.1,
52            timingFunction: .easeOut
53        )
54
55        // Geri küçül
56        DispatchQueue.main.asyncAfter(deadline: .now() + 0.1) {
57            var originalTransform = entity.transform
58            originalTransform.scale = SIMD3<Float>(1, 1, 1)
59            entity.move(
60                to: originalTransform,
61                relativeTo: entity.parent,
62                duration: 0.1,
63                timingFunction: .easeIn
64            )
65        }
66    }
67}

1import RealityKit
2
3// Custom component tanımlama
4struct RotationComponent: Component {
5    var speed: Float = 1.0
6    var axis: SIMD3<Float> = [0, 1, 0]
7    var isRotating: Bool = true
8}
9
10struct FloatingComponent: Component {
11    var amplitude: Float = 0.05
12    var frequency: Float = 1.0
13    var startHeight: Float = 0
14    var timeOffset: Float = 0
15}
16
17struct GlowComponent: Component {
18    var color: SIMD3<Float> = [1, 0.8, 0.2]
19    var intensity: Float = 2.0
20    var pulseSpeed: Float = 1.5
21}
22
23// RealityKit 4: System tanımlama
24class RotationSystem: System {
25    static let query = EntityQuery(
26        where: .has(RotationComponent.self)
27    )
28
29    required init(scene: Scene) {}
30
31    func update(context: SceneUpdateContext) {
32        for entity in context.entities(
33            matching: Self.query,
34            updatingSystemWhen: .rendering
35        ) {
36            guard var rotation = entity.components[RotationComponent.self],
37                  rotation.isRotating else { continue }
38
39            let angle = rotation.speed * Float(context.deltaTime)
40            let rotationQuaternion = simd_quatf(
41                angle: angle,
42                axis: rotation.axis
43            )
44            entity.orientation = entity.orientation * rotationQuaternion
45        }
46    }
47}
48
49class FloatingSystem: System {
50    static let query = EntityQuery(
51        where: .has(FloatingComponent.self)
52    )
53
54    required init(scene: Scene) {}
55
56    func update(context: SceneUpdateContext) {
57        let time = Float(Date().timeIntervalSince1970)
58
59        for entity in context.entities(
60            matching: Self.query,
61            updatingSystemWhen: .rendering
62        ) {
63            guard var floating = entity.components[FloatingComponent.self] else { continue }
64
65            let yOffset = floating.amplitude * sin(
66                floating.frequency * time + floating.timeOffset
67            )
68            entity.position.y = floating.startHeight + yOffset
69        }
70    }
71}
72
73// Entity factory: Component'ları bir araya getir
74class SpatialEntityFactory {
75    static func createFloatingOrb(
76        at position: SIMD3<Float>,
77        color: UIColor = .systemCyan
78    ) -> ModelEntity {
79        let orb = ModelEntity(
80            mesh: .generateSphere(radius: 0.08),
81            materials: [
82                PhysicallyBasedMaterial.makeEmissive(color: color, intensity: 2.0)
83            ]
84        )
85
86        orb.position = position
87
88        // Component'ları ekle
89        orb.components.set(RotationComponent(speed: 0.5))
90        orb.components.set(FloatingComponent(
91            amplitude: 0.03,
92            frequency: 0.8,
93            startHeight: position.y,
94            timeOffset: Float.random(in: 0...Float.pi * 2)
95        ))
96        orb.components.set(InputTargetComponent())
97        orb.components.set(CollisionComponent(
98            shapes: [.generateSphere(radius: 0.08)]
99        ))
100        orb.components.set(HoverEffectComponent())
101
102        return orb
103    }
104}
105
106extension PhysicallyBasedMaterial {
107    static func makeEmissive(
108        color: UIColor,
109        intensity: Float
110    ) -> PhysicallyBasedMaterial {
111        var material = PhysicallyBasedMaterial()
112        material.baseColor = .init(tint: color)
113        material.emissiveColor = .init(color: color)
114        material.emissiveIntensity = intensity
115        material.roughness = .init(floatLiteral: 0.1)
116        material.metallic = .init(floatLiteral: 0.0)
117        return material
118    }
119}

1import SwiftUI
2import RealityKit
3
4struct ImmersiveView: View {
5    @Environment(\.scenePhase) private var scenePhase
6    @StateObject private var sceneManager = ImmersiveSceneManager()
7
8    var body: some View {
9        RealityView { content, attachments in
10            await sceneManager.setupScene(content: content)
11        } update: { content, attachments in
12            sceneManager.updateScene(content: content)
13        } attachments: {
14            // SwiftUI view'leri 3D uzaya yerleştir
15            Attachment(id: "info-panel") {
16                InfoPanelView(manager: sceneManager)
17                    .frame(width: 400, height: 300)
18            }
19        }
20        .task {
21            await sceneManager.startTracking()
22        }
23        // Scene phase değişimlerini handle et
24        .onChange(of: scenePhase) { _, newPhase in
25            switch newPhase {
26            case .active:
27                sceneManager.resumeExperience()
28            case .inactive:
29                // Telefon geldi veya notification — geçici durdur
30                sceneManager.pauseExperience()
31            case .background:
32                // Kullanıcı başka uygulamaya geçti — tamamen durdur
33                sceneManager.suspendExperience()
34            @unknown default:
35                break
36            }
37        }
38    }
39}
40
41class ImmersiveSceneManager: ObservableObject {
42    @Published var isExperienceActive = false
43    @Published var frameCount = 0
44
45    private var updateTask: Task<Void, Never>?
46
47    func setupScene(content: RealityViewContent) async {
48        // Sahneyi hazırla
49        isExperienceActive = true
50    }
51
52    func updateScene(content: RealityViewContent) {
53        frameCount += 1
54    }
55
56    func startTracking() async {
57        // ARKit ve diğer tracking başlat
58    }
59
60    func pauseExperience() {
61        // Animasyonları duraklat, tracking'i kısıtla
62        isExperienceActive = false
63        updateTask?.cancel()
64    }
65
66    func resumeExperience() {
67        isExperienceActive = true
68        startUpdateLoop()
69    }
70
71    func suspendExperience() {
72        pauseExperience()
73        // Kaynakları serbest bırak
74    }
75
76    private func startUpdateLoop() {
77        updateTask = Task {
78            while !Task.isCancelled && isExperienceActive {
79                await Task.yield()
80            }
81        }
82    }
83}

1import RealityKit
2
3class ModelLoader {
4    // Async model yükleme
5    func loadModel(named name: String) async throws -> ModelEntity {
6        let entity = try await ModelEntity(
7            named: name,
8            in: .main
9        )
10
11        // LOD ayarları
12        if var modelComponent = entity.components[ModelComponent.self] {
13            // Uzak mesafe için düşük detail
14            entity.components.set(modelComponent)
15        }
16
17        return entity
18    }
19
20    // Birden fazla modeli paralel yükle
21    func loadMultipleModels(names: [String]) async throws -> [ModelEntity] {
22        return try await withThrowingTaskGroup(of: ModelEntity.self) { group in
23            for name in names {
24                group.addTask {
25                    try await self.loadModel(named: name)
26                }
27            }
28
29            var models: [ModelEntity] = []
30            for try await model in group {
31                models.append(model)
32            }
33            return models
34        }
35    }
36
37    // Texture streaming — büyük asset"ler için
38    func preloadTextures(for entity: ModelEntity) async {
39        // Entity"nin tüm texture"larını önceden belleğe al
40        guard let modelComponent = entity.components[ModelComponent.self] else {
41            return
42        }
43
44        // Material texture"larını iterate et
45        for var material in modelComponent.materials {
46            // PhysicallyBasedMaterial için texture preload
47            if var pbr = material as? PhysicallyBasedMaterial {
48                // BaseColor texture
49                if let baseColorTexture = pbr.baseColor.texture {
50                    _ = baseColorTexture.resource
51                }
52            }
53        }
54    }
55}

1import SwiftUI
2import RealityKit
3
4struct SpatialGestureView: View {
5    @State private var dragOffset: SIMD3<Float> = .zero
6    @State private var scale: Float = 1.0
7    @State private var rotation: simd_quatf = .init(ix: 0, iy: 0, iz: 0, r: 1)
8
9    var body: some View {
10        RealityView { content in
11            let box = ModelEntity(
12                mesh: .generateBox(size: 0.2, cornerRadius: 0.02),
13                materials: [SimpleMaterial(
14                    color: .systemIndigo,
15                    isMetallic: true
16                )]
17            )
18            box.name = "main-box"
19            box.components.set(InputTargetComponent())
20            box.components.set(CollisionComponent(
21                shapes: [.generateBox(size: [0.2, 0.2, 0.2])]
22            ))
23            box.components.set(HoverEffectComponent())
24            content.add(box)
25        }
26        // Drag gesture
27        .gesture(
28            DragGesture()
29                .targetedToAnyEntity()
30                .onChanged { value in
31                    let translation = value.convert(
32                        value.gestureValue.translation3D,
33                        from: .local,
34                        to: .scene
35                    )
36                    value.entity.position = value.startTargetedEntity.position + SIMD3<Float>(translation)
37                }
38        )
39        // Magnify (scale) gesture
40        .gesture(
41            MagnifyGesture()
42                .targetedToAnyEntity()
43                .onChanged { value in
44                    let newScale = Float(value.gestureValue.magnification)
45                    value.entity.scale = SIMD3<Float>(
46                        repeating: max(0.1, min(3.0, newScale))
47                    )
48                }
49        )
50        // Rotate gesture
51        .gesture(
52            RotateGesture3D()
53                .targetedToAnyEntity()
54                .onChanged { value in
55                    let rotation = simd_quatf(value.gestureValue.rotation)
56                    value.entity.orientation = rotation
57                }
58        )
59    }
60}

1import RealityKit
2
3class PhysicsSceneBuilder {
4    func buildPhysicsScene(in content: RealityViewContent) {
5        // Zemin düzlemi
6        let floorMesh = MeshResource.generatePlane(
7            width: 2,
8            depth: 2
9        )
10        let floorMaterial = SimpleMaterial(
11            color: .systemGray6,
12            isMetallic: false
13        )
14        let floorEntity = ModelEntity(
15            mesh: floorMesh,
16            materials: [floorMaterial]
17        )
18        floorEntity.position = [0, 0, -1]
19
20        // Static physics body — hareket etmez ama çarpışma alır
21        floorEntity.components.set(PhysicsBodyComponent(
22            massProperties: .default,
23            material: .generate(
24                staticFriction: 0.6,
25                dynamicFriction: 0.4,
26                restitution: 0.3
27            ),
28            mode: .static
29        ))
30        floorEntity.components.set(CollisionComponent(
31            shapes: [.generateBox(size: [2, 0.01, 2])]
32        ))
33        content.add(floorEntity)
34
35        // Dinamik objeler
36        for i in 0..<5 {
37            let cube = createPhysicsCube(
38                at: [
39                    Float.random(in: -0.4...0.4),
40                    1.0 + Float(i) * 0.3,
41                    -0.8
42                ]
43            )
44            content.add(cube)
45        }
46    }
47
48    private func createPhysicsCube(at position: SIMD3<Float>) -> ModelEntity {
49        let size: Float = 0.08
50        let cube = ModelEntity(
51            mesh: .generateBox(size: size, cornerRadius: 0.005),
52            materials: [SimpleMaterial(
53                color: [.systemRed, .systemOrange, .systemYellow,
54                        .systemGreen, .systemBlue].randomElement()!,
55                isMetallic: false
56            )]
57        )
58        cube.position = position
59
60        // Dynamic physics body — yerçekimine tabi
61        cube.components.set(PhysicsBodyComponent(
62            massProperties: .init(mass: 0.1),
63            material: .generate(
64                staticFriction: 0.5,
65                dynamicFriction: 0.3,
66                restitution: 0.4
67            ),
68            mode: .dynamic
69        ))
70        cube.components.set(CollisionComponent(
71            shapes: [.generateBox(size: [size, size, size])]
72        ))
73        cube.components.set(InputTargetComponent())
74
75        return cube
76    }
77}
